Method to Create Aggregate Tree for Hardware Supported Collectives

Chen Shuping; Wei Hongmei; Wang Fei; Li Yi; He Wangquan; Qi Fengbin

doi:10.7544/issn1000-1239.202220684

Journal of Computer Research and Development > 2024 > 61(2): 503-517. > DOI: 10.7544/issn1000-1239.202220684 CSTR: 32373.14.issn1000-1239.202220684

Chen Shuping, Wei Hongmei, Wang Fei, Li Yi, He Wangquan, Qi Fengbin. Method to Create Aggregate Tree for Hardware Supported Collectives[J]. Journal of Computer Research and Development, 2024, 61(2): 503-517. DOI: 10.7544/issn1000-1239.202220684

Citation:

PDF (2680 KB)

Method to Create Aggregate Tree for Hardware Supported Collectives

National Research Center of Parallel Computer Engineering & Technology, Beijing 100190

Funds: This work was supported by the National Key Research and Development Program of China (2020YFB0204602).

More Information

Author Bio:
Chen Shuping: born in 1983. PhD, associate professor. His main research interests include high performance computing and interconnect networks

Wei Hongmei: born in 1968. professor, PhD supervisor. Member of CCF. Her research interests include parallel computing and parallel compilation

Wang Fei: born in 1981. Associate professor. His research interests include compiler design and optimization, and artificial intelligence

Li Yi: born in 1994. Master, engineer. Her main research interests include high performance computing and high-speed interconnect networks

He Wangquan: born in 1975. PhD, professor. His research interests include parallel programming language design and compiler optimization

Qi Fengbin: born in 1966. Professor, PhD supervisor. Fellow of CCF. His research interests include high performance computing architecture, compiler optimization, and parallel algorithm
Received Date: August 07, 2022
Revised Date: April 05, 2023
Available Online: November 13, 2023

Graphical Abstract

Abstract

Abstract

Traditional MPI (message passing interface) collectives are implemented by point-to-point messages, and have poor performance. Hardware supported collectives have attracted more and more attention due to their high performance and low CPU utilization. Aggregate tree has crucial impact on the performance of hardware supported collectives. We study the factors that affect the performance of hardware supported collectives, and propose a cost model for hardware supported collectives and an efficient method to create aggregate trees. The method includes three parts. Firstly, we choose appropriate aggregate tree type and breadth according to the operation type and the size of aggregate messages to do tradeoff between network transmission time and data processing time. Secondly, we propose a method to create hierarchical minimum height aggregate tree of type Ⅰ, which reduces the number of inter-group communication. Thirdly, we put forward a method to create the minimum cost aggregate tree of type Ⅱ, which minimizes the number of used switches. In the Sunway interconnection network, we test the proposals. In the presence of network noise, the message latency of the hierarchical minimum height aggregate tree of type Ⅰ is reduced by 24%−89% compared with that of the traditional method. The aggregate entries used by the minimum cost aggregate tree of type Ⅱ for typical communication patterns are reduced by 90% compared with that of the traditional method.
- MPI collectives,
- aggregate tree,
- cost model,
- high-speed interconnect,
- high-performance computing

FullText(HTML)
