ChatModeler: A Human-Machine Collaborative and Iterative Requirements Elicitation and Modeling Approach via Large Language Models

Jin Dongming; Jin Zhi; Chen Xiaohong; Wang Chunhui

doi:10.7544/issn1000-1239.202330746

Journal of Computer Research and Development > 2024 > 61(2): 338-350. > DOI: 10.7544/issn1000-1239.202330746 CSTR: 32373.14.issn1000-1239.202330746

Jin Dongming, Jin Zhi, Chen Xiaohong, Wang Chunhui. ChatModeler: A Human-Machine Collaborative and Iterative Requirements Elicitation and Modeling Approach via Large Language Models[J]. Journal of Computer Research and Development, 2024, 61(2): 338-350. DOI: 10.7544/issn1000-1239.202330746

Citation:

PDF (1215 KB)

ChatModeler: A Human-Machine Collaborative and Iterative Requirements Elicitation and Modeling Approach via Large Language Models

Jin Dongming^{1, 2,},
Jin Zhi^{1, 2, ,},
Chen Xiaohong³,
Wang Chunhui⁴

1.
School of Computer Science, Peking University, Beijing 100871
2.
Key Laboratory of High Confidence Software Technologies (Peking University) , Ministry of Education, Beijing 100871
3.
Shanghai Key Laboratory of Trustworthy Computing (East China Normal University), Shanghai 200050
4.
College of Computer Science and Technology, Inner Mongolia Normal University, Inner Mongolia 010011

Funds: This work was supported by the National Natural Science Foundation of China (62192730, 62192731, 62162051).

More Information

Author Bio:
Jin Dongming: born in 2001. PhD candidate. His main research interest includes intelligent requirements engineering

Jin Zhi: born in 1962. PhD, professor. Her main research interests include requirements engineering and software automation

Chen Xiaohong: born in 1982. PhD, associate professor. Her main research interests include requirements engineering, and knowledge based software engineering and formal method

Wang Chunhui: born in 1979. PhD, associate professor. Her main research interests include software engineering and requirements engineering
Received Date: September 11, 2023
Revised Date: December 11, 2023
Available Online: December 20, 2023

Graphical Abstract

Abstract

Abstract

Requirements elicitation and modeling is a critical step in requirements engineering that affects subsequent system design and implementation. Traditional requirements elicitation and modeling methods usually involve multiple types of stakeholders, such as requirement providers and requirements analysts, working together in an iterative manner, which requires a lot of manpower. It is important to reduce the burden of requirements providers and requirements analysts and improve the efficiency of elicitation and modeling. Some of the existing efforts use knowledge bases to provide more knowledge to assist modeling or elicitation, and some use natural language processing techniques to automate the elicitation or modeling process. But they do not reduce the burden of requirements providers. Leveraging the generative capability of LLMs (large language models), we provide ChatModeler, a requirement elicitation and modeling framework for iterative human-machine collaboration. Specifically, based on the division of labor and collaboration relationship of real-world requirements teams, some work of requirements providers and requirements analysts is taken up by LLMs, while requirements providers only need to perform confirmation. In this paper, prompts are designed for the various roles played by the various LLMs, which varies with the meta-model of the requirements. ChatModeler is used in 14 sets of comparative experiments with state-of-the-art automated modeling approaches for three types of requirement models on seven requirement cases, demonstrating the superiority of ChatModeler in both reducing the number of interactions of the requirements provider and generating higher quality requirement models.
- requirements engineering,
- requirements elicitation,
- large language models,
- human-machine collaboration,
- prompt engineering
