Rapid Single-Flux-Quantum Circuit Routing Algorithm Considering Length Matching

Liu Genggeng^{1, 2,},
Yu Yantao^{1, 2},
Zhou Ruping^{1, 2},
Wei Rongshan^3, ,,
Xu Ning⁴

1.
College of Computer and Data Science, Fuzhou University, Fuzhou 350116
2.
Fujian Key Laboratory of Network Computing and Intelligent Information Processing (Fuzhou University), Fuzhou 350116
3.
College of Physics and Information Engineering, Fuzhou University, Fuzhou 350108
4.
School of Information Engineering, Wuhan University of Technology, Wuhan 430070

Funds: This work was supported by the National Natural Science Foundation of China (62372109) and the Fujian Science Foundation for Distinguished Young Scholars (2023J06017).

More Information

Author Bio:
Liu Genggeng: born in 1988. PhD, professor, PhD supervisor. Distinguished member of CCF. His main research interests include design automation for microfluidic biochips and integrated circuits

Yu Yantao: born in 2000. Master candidate. Student member of CCF. His main research interest includes VLSI routing

Zhou Ruping: born in 1998. PhD candidate. Student member of CCF. Her main research interests include VLSI routing and clock tree synthesis

Wei Rongshan: born in 1980. PhD, professor, PhD supervisor. His main research interests include intelligent sensor chip design, and artificial intelligence chip design for deep learning and other applications

Xu Ning: born in 1968. PhD, professor, PhD supervisor. Senior member of CCF. His main research interests include electronic design automation, design automation for integrated circuits, and artificial intelligence
Received Date: February 01, 2024
Revised Date: October 15, 2024
Accepted Date: November 12, 2024
Available Online: November 18, 2024

Graphical Abstract

Abstract

Abstract

The high frequency characteristics of rapid single-flux-quantum (RSFQ) circuits poses a great challenge to circuit layout design. In order to solve the circuit delay problem caused by the high frequency characteristics of RSFQ, delay elements such as passive transmission line can be used in the routing stage. The delay of a passive transmission line is roughly proportional to its length, and the power consumption of the passive transmission line does not increase with the increase of the wirelength, so length matching routing is a crucial problem for RSFQ circuits. Therefore, we propose an efficient RSFQ circuit routing algorithm considering length matching, including the following key strategies: 1) when generating the initial path, a method of detour routing is presented to meet the partial length matching of passive transmission lines without changing the initial routing space; 2) an iterative resource insertion algorithm based on region-awareness is utilized to reduce the area of additional resources needed to be added; 3) a length-matching driven routing algorithm considering blocking cost is designed, which improves the resource utilization of routing space. Experimental results show that, compared with existing multi-terminal routing algorithms, the proposed algorithm reduces the area required for routing by 8% and the running time by 36%, thus achieving fast and high-quality routing results.
- rapid single-flux-quantum circuit,
- physical design,
- time matching,
- length matching,
- channel routing
