Shuffle-SRAM: In-SRAM Parallel Bitwise Data Shuffle

Zhang Dunbo; Zeng Lingling; Wang Ruoxi; Wang Yaohua; Shen Li

doi:10.7544/issn1000-1239.202330151

Journal of Computer Research and Development > 2025 > 62(1): 75-89. > DOI: 10.7544/issn1000-1239.202330151 CSTR: 32373.14.issn1000-1239.202330151

Zhang Dunbo, Zeng Lingling, Wang Ruoxi, Wang Yaohua, Shen Li. Shuffle-SRAM: In-SRAM Parallel Bitwise Data Shuffle[J]. Journal of Computer Research and Development, 2025, 62(1): 75-89. DOI: 10.7544/issn1000-1239.202330151

Citation:

PDF (2440 KB)

Shuffle-SRAM: In-SRAM Parallel Bitwise Data Shuffle

1.
College of Computer Science and Technology, National University of Defense Technology, Changsha 410073
2.
Key Laboratory of Advanced Microprocessors Chips and Systems (National University of Defense Technology), Changsha 410073

Funds: This work was supported by the National Natural Science Foundation of China (61972407).

More Information

Author Bio:
Zhang Dunbo: born in 1996. PhD candidate. His main research interests include computer architecture, processing-in-memory and SRAM

Zeng Lingling: born in 1996. Master candidate. His main research interests include computer architecture, processing-in-memory and SRAM

Wang Ruoxi: born in 2000. Master. Her main research interest includes computer architecture

Wang Yaohua: born in 1985. PhD, professor, PhD supervisor. His main research interests include high performance computing, accelerator architecture, and memory system optimization

Shen Li: born in 1976. PhD, professor, PhD supervisor. His main research interests include multi/many-core architecture, runtime & compilation optimization, processing-in-memory, and high performance computing
Received Date: March 09, 2023
Revised Date: January 14, 2024
Available Online: November 12, 2024

Graphical Abstract

Abstract

Abstract

While vector processing unit is widely employed in processors for neural networks, signal processing, and high performance computing, it suffers from expensive shuffle operations dedicated to data alignment. Traditionally, processors handle shuffle operations with its data shuffle unit. However, data shuffle unit will introduce expensive overhead of data movement and only can shuffle data in serial. In fact, shuffle operations only change the layout of data and ideally should be done entirely within memory. Nowadays, SRAM is no longer just a storage component, but also as a computing unit. To this end, we propose Shuffle-SRAM in this paper, and Shuffle-SRAM can shuffle multiple data elements simultaneously bit by bit within an SRAM bank. The key idea is to exploit the bit-line wise data movement ability in SRAM so as to shuffle multiple data in parallel, where all the bits of different data elements on the same bit-line of SRAM can be shuffled simultaneously, achieving a high level of parallelism. Through suitable data layout preparation and the vector shuffle extension instructions, Shuffle-SRAM efficiently supports a wide range of commonly used shuffle operations efficiently. Our evaluation results show that Shuffle-SRAM can achieve a performance gain of 28 times for commonly used shuffle operations and 3.18 times for real world applications including FFT, AlexNet, and VggNet. The SRAM area overhead only increases by 4.4%.
