OpenPlanner: An Open-Source Traffic Planning for Time-Sensitive Networking

Jiang Xuyan; Quan Wei; Fu Wenwen; Zhang Xiaoliang; Sun Zhigang

doi:10.7544/issn1000-1239.202330776

Journal of Computer Research and Development > 2025 > 62(5): 1307-1329. > DOI: 10.7544/issn1000-1239.202330776 CSTR: 32373.14.issn1000-1239.202330776

Jiang Xuyan, Quan Wei, Fu Wenwen, Zhang Xiaoliang, Sun Zhigang. OpenPlanner: An Open-Source Traffic Planning for Time-Sensitive Networking[J]. Journal of Computer Research and Development, 2025, 62(5): 1307-1329. DOI: 10.7544/issn1000-1239.202330776

Citation:

PDF (3644 KB)

OpenPlanner: An Open-Source Traffic Planning for Time-Sensitive Networking

1.
College of Computer Science and Technology, National University of Defense Technology, Changsha 410003
2.
College of Computer Science and Technology, Nanjing University of Aeronautics and Astronautics, Nanjing 211106
3.
College of Information Engineering, Hunan Automotive Engineering Vocational University, Zhuzhou, Hunan 412001

Funds: This work was supported by the Foundation of National Key Laboratory (2023-KJWPDL-14) and Postgraduate Scientific Research Innovation Project of Hunan Province (CX20220013).

More Information

Author Bio:
Jiang Xuyan: born in 1998. PhD candidate. Her main research interests include time-sensitive networking and FPGA design

Quan Wei: born in 1987. PhD, associate professor. His main research interests include time-sensitive networking, software-defined networking and FPGA design

Fu Wenwen: born in 1994. PhD, assistant professor. His main research interests include programmable network and time-sensitive networking

Zhang Xiaoliang: born in 1991. Master, lecturer. His main research interests include software-defined networking and time-sensitive networking

Sun Zhigang: born in 1974. PhD, professor. His main research interests include software-defined networking, time-sensitive networking, network architecture, and FPGA design and network security
Received Date: September 27, 2023
Revised Date: December 04, 2024
Accepted Date: January 08, 2025
Available Online: January 08, 2025

Graphical Abstract

Abstract

Abstract

Time-sensitive networking (TSN) has emerged as a primary choice for communication in distributed real-time systems such as industrial automation, avionics, and automotive applications. TSN traffic planning aims to allocate conflict-free transmission times for time-sensitive frames while managing constraints related to network topology, resources, device capabilities, and stream requirements. The traffic planning problem is NP-complete. There is a need of quick development of open-source traffic planning software for both academia and industry. We introduce LOCAP, an architecture for TSN planning with interfaces named minimum collection of planning and general table of planning. LOCAP separates planning algorithms and tools, as well as planning software and hardware details. Based on LOCAP, we implement an open-source TSN planner called OpenPlanner. OpenPlanner integrates multiple algorithms that leverage satisfiability modulo theories and heuristics to solve planning problems. We evaluate the runtime and solution quality of various algorithms using OpenPlanner, highlighting the need for diverse planning algorithms in different TSN applications. To the best of our knowledge, OpenPlanner is the first open-source TSN planner. Its planning results have been deployed on multiple hardware platforms, including OpenTSN, Yinhe Hengxin TSN chip, and XZ-TTE. It has been applied in various systems such as satellites, unmanned vehicles, and artillery.
- time-sensitive networking (TSN),
- traffic planning,
- open-source,
- satisfiability modulo theories,
- time-aware shaper
