Bitsliced Optimization of SM4 Algorithm with the SIMD Instruction Set

Wang Chuang; Ding Yan; Huang Chenlin; Song Liantao

doi:10.7544/issn1000-1239.202220531

Journal of Computer Research and Development > 2024 > 61(8): 2097-2109. > DOI: 10.7544/issn1000-1239.202220531 CSTR: 32373.14.issn1000-1239.202220531

Wang Chuang, Ding Yan, Huang Chenlin, Song Liantao. Bitsliced Optimization of SM4 Algorithm with the SIMD Instruction Set[J]. Journal of Computer Research and Development, 2024, 61(8): 2097-2109. DOI: 10.7544/issn1000-1239.202220531

Citation:

PDF (2419 KB)

Bitsliced Optimization of SM4 Algorithm with the SIMD Instruction Set

College of Computer Science and Technology, National University of Defense Technology, Changsha 410073

Funds: This work was supported by the Joint Funds of the National Natural Science Foundation of China (U19A2060), the National Natural Science Foundation of China (62172431), the National Defense Science and Technology Foundation Strengthening Project of China (2019-XXX-ZD-188-00), and the Hunan Provincial Innovation Foundation for Postgraduate (CX20220056).

More Information

Author Bio:
Wang Chuang: born in 1997. Master. His main research interests include smart contract of blockchain and cryptography algorithm optimization

Ding Yan: born in 1977. PhD, associate professor. Distinguished member of CCF. Her main research interests include operating system, system security, and trusted cloud computing

Huang Chenlin: born in 1976. PhD, professor. Member of CCF. His main research interests include operating system, system security, and smart security. (clhuang@nudt.edu.cn)

Song Liantao: born in 1998. PhD candidate. His main research interests include system security and trusted computing. ( songliantao@nudt.edu.cn)
Received Date: June 10, 2022
Revised Date: November 09, 2023
Available Online: March 13, 2024

Graphical Abstract

Abstract

Abstract

SM4 algorithm is a commercial block cipher algorithm independently designed by China, and its encryption and decryption performance has become one of the critical factors affecting the data confidentiality of the information system. The existing optimizations mainly focus on hardware designs and software look-up tables, which have problems such as dependence on specific hardware environments, low efficiency, and vulnerability to side-channel attacks. Bit slicing technology efficiently processes block ciphers in parallel by reorganizing input data, and can resist side-channel attacks against caches. However, the existing researches on bitsliced block ciphers are highly dependent on the hardware platforms and only support a single processor architecture, and the parallel processing pipeline starts slowly. It is difficult for the encryption and decryption operations for small-scale data to give full play to the advantages of advanced instruction sets such as SIMD (single instruction multiple data) instructions. To resolve the above problems, we firstly propose a cross-platform general bitsliced block cipher algorithm model, which supports a general data slicing method that provides consistent data slicing for different processor instructions. Based on that, a fine-grained bitsliced SM4 optimization algorithm for SIMD instructions is proposed, which can effectively shorten the startup time of the algorithm through fine-grained plaintext slicing reorganization and linear transformation optimization. The experiments show that, compared with the look-up table-based SM4 algorithm, the encryption rate can reach up to 438.0 MBps. The clock cycles required for encrypting a byte are up to 7.0 CPB (cycle/B), and the encryption performance is improved by an average of 80.4% to 430.3%.
- SM4 algorithm,
- performance optimization,
- bit slice,
- side-channel attacks,
- SIMD instruction set
